FEATURES:
Servo motor control
Remote control
Wide range voltage regulation
Automatic voltage regulation
Display:LED/LCD digital meter display
Protection functions:over voltage,overload,over temperature low voltage,time delay,Motor jammed protection
Waveform distortion:no additional waveform distortion
Dielectric strength:1500V/1min
Insulation resistance:≥2MΩ
SPECIFICATIONS
Input voltage | 140-260V AC |
Input frequency | 50/60Hz |
Output voltage | 220V AC/110V AC |
Output precision | 220V+/-3%,110V+/-6% |
Time delay | 3′s short time,180′s long time |
Load power factor | 0.8 |
Phase | single phase |
Operating temperature | 0-40℃ |
Storage temperature | -15℃-45℃ |
Operating relative humidity | 10%RH-102%RH |
Customize option for specification and availability please contact TAILEI | |
DIMENSION WEIGHT
MODEL | QTY/CTN | DIMENSION(cm) | G.W.(kg) | N.W.(kg) | QTY IN 20′ft (PCS) |
SVC-E 500VA | 4 | 42.5*25.5*36 | 16.5 | 14.5 | 2868 |
SVC-E 1KVA | 4 | 50*27.5*39.5 | 19.5 | 18 | 2070 |
SVC-E 1.5KVA | 4 | 50*27.5*39.5 | 23.5 | 22 | 2070 |
SVC-E 2KVA | 2 | 60*33*25.5 | 17.8 | 16 | 1100 |
SVC-E 3KVA | 2 | 57*37.5*29.5 | 22 | 20 | 880 |
SVC-E 5KVA | 1 | 49*40*28.5 | 17.5 | 15 | 500 |
SVC-E 8KVA | 1 | 49*40*28.5 | 22.5 | 21 | 500 |
SVC-E 10KVA | 1 | 49*40*28.5 | 25.5 | 24 | 500 |
SVC-E 15KVA | 1 | 49.5*53*82 | 67 | 60 | 130 |
SVE-E 20KVA | 1 | 49.5*53*82 | 72 | 65 | 130 |
SVE-E 30KVA | 1 | 50*55*92 | 85 | 76 | 105 |
FEATURES:
Servo motor control
Remote control
Wide range voltage regulation
Automatic voltage regulation
Display:LED/LCD digital meter display
Protection functions:over voltage,overload,over temperature low voltage,time delay,Motor jammed protection
Waveform distortion:no additional waveform distortion
Dielectric strength:1500V/1min
Insulation resistance:≥2MΩ
SPECIFICATIONS
Input voltage | 140-260V AC |
Input frequency | 50/60Hz |
Output voltage | 220V AC/110V AC |
Output precision | 220V+/-3%,110V+/-6% |
Time delay | 3′s short time,180′s long time |
Load power factor | 0.8 |
Phase | single phase |
Operating temperature | 0-40℃ |
Storage temperature | -15℃-45℃ |
Operating relative humidity | 10%RH-102%RH |
Customize option for specification and availability please contact TAILEI | |
DIMENSION WEIGHT
MODEL | QTY/CTN | DIMENSION(cm) | G.W.(kg) | N.W.(kg) | QTY IN 20′ft (PCS) |
SVC-E 500VA | 4 | 42.5*25.5*36 | 16.5 | 14.5 | 2868 |
SVC-E 1KVA | 4 | 50*27.5*39.5 | 19.5 | 18 | 2070 |
SVC-E 1.5KVA | 4 | 50*27.5*39.5 | 23.5 | 22 | 2070 |
SVC-E 2KVA | 2 | 60*33*25.5 | 17.8 | 16 | 1100 |
SVC-E 3KVA | 2 | 57*37.5*29.5 | 22 | 20 | 880 |
SVC-E 5KVA | 1 | 49*40*28.5 | 17.5 | 15 | 500 |
SVC-E 8KVA | 1 | 49*40*28.5 | 22.5 | 21 | 500 |
SVC-E 10KVA | 1 | 49*40*28.5 | 25.5 | 24 | 500 |
SVC-E 15KVA | 1 | 49.5*53*82 | 67 | 60 | 130 |
SVE-E 20KVA | 1 | 49.5*53*82 | 72 | 65 | 130 |
SVE-E 30KVA | 1 | 50*55*92 | 85 | 76 | 105 |
